756-3204/190-100

Specifications

Technical Data

• Connection type: M23 socket - Free end
• Pole No.: 19
• Cable connection direction to mating direction: 90 °
• Cable length: 10 m
• Operating voltage: ≤ 300 V
• Operating current: 8 A || 10 mm² 1 A
• Rated surge voltage: ≥ 2.0 kV rms

Mechanical Data

• Bending cycles: 2 Mio.
• Drag chain suitability: Yes
• Sheathed cable diameter: 11.3 … 11.9 mm
• Weight: 1438.000 g
• Color: Black

Environmental Requirements

• Surrounding air (operating) temperature (dynamic): -25 … +80 °C
• Surrounding air (operating) temperature (static): -40 … +80 °C
• Protection type: IP67
• Fire load: 0.000 MJ

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918569088
• Customs tariff number Sales Organisation Germany: 85444290900
