782-613

782-613
N-COND DISC TB 41A 8MM
Manufacturer Wago
SKU 782-613
MPN 782-613

Our price: $7.24

Please Contact Us for Stock Availability

Qty

Features

Approvals

  • DEKRA Certification B.V., CCA, NTR NL-7522, EN 60947
  • Det Norske Veritas, Germanischer Lloyd, DNV GL, TAE0001V2
  • Underwriters Laboratories Inc., UR, E45172, UL 1059
  • Bureau Veritas S.A., BV, 07436/F0 BV, EN 60947
  • DEKRA Certification B.V., CCA, 2195540.01, EN 60947
  • Lloyds Register, LR, 91/20112 (E9), EN 60947

Specifications

Ratings Per Iec/En

  • Nominal voltage (III/3): 400 V
  • Rated surge voltage (III/3): 6 kV
  • Rated current: 41 A
  • Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3

Connection 1

  • Connection technology: CAGE CLAMP®
  • Actuation type: Operating tool
  • Connectable conductor materials: Copper
  • Solid conductor: 0.2 … 6 mm² / 24 … 10 AWG
  • Fine-stranded conductor: 0.2 … 6 mm² / 24 … 10 AWG
  • Strip length: 12 … 13 mm / 0.47 … 0.51 inch
  • Wiring direction: Front-entry wiring

Physical Data

  • Width: 8 mm / 0.315 inch
  • Height: 82.5 mm / 3.248 inch
  • Depth from upper edge of DIN-rail: 43.5 mm / 1.713 inch

Mechanical Data

  • Design: Angled
  • Mounting type: DIN-35 rail
  • Marking level: Center marking

Material Data

  • Color: Blue
  • Flammability class per UL94: V0
  • Fire load: 0.002 MJ
  • Weight: 24.980 g

Commercial Data

  • Packaging type: Box
  • Country of origin Sales Organisation Germany: PL
  • GTIN: 4045454186852
  • Customs tariff number Sales Organisation Germany: 85365080900
