785-607

Features

Approvals

• DEKRA Certification B.V., KEMA/KEUR, 71-101911, EN 60947
• DEKRA Certification B.V., CCA, NTR NL-7707, EN 60947
• DEKRA Certification B.V., CSA, 1632550, C22.2 No. 158
• Underwriters Laboratories Inc., UR, E45172, UL 1059

Specifications

Notes

• Safety information 1: Only suitable for DIN 35 x 15 rail

Ratings Per Iec/En

• Ratings per: IEC/EN 60947-7-2

Connection 1

• Connection technology: CAGE CLAMP®
• Actuation type: Operating tool
• Connectable conductor materials: Copper
• Solid conductor: 6 … 35 mm² / 8 … 2 AWG
• Strip length: 23 mm / 0.91 inch
• Wiring direction: Front-entry wiring

Physical Data

• Width: 16 mm / 0.63 inch
• Height: 114 mm / 4.488 inch
• Depth from upper edge of DIN-rail: 44.5 mm / 1.752 inch

Mechanical Data

• Design: Angled
• Mounting type: DIN-35 rail
• Marking level: Center/side marking

Material Data

• Color: Green-yellow
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Fire load: 1.101 MJ
• Weight: 105.000 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4045454902650
• Customs tariff number Sales Organisation Germany: 85369010000
