237-103

Features

Approvals

• UL International Germany GmbH, UL, E45172, UL 1059
• DEKRA Certification B.V., CCA, 2160584.33, EN 60947
• DEKRA Certification B.V., CSA, 70048844, C22.2 No. 158
• DEKRA Certification B.V., CCA, NTR NL-7137, EN 60947

Specifications

Ratings Per Iec/En

• Ratings per: IEC/EN 60664-1
• Rated voltage (III/2): 250 V
• Rated surge voltage (III/2): 2.5 kV
• Rated current: 16 A
• Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2

Connection 1

• Connection technology: Screw-type connection
• Actuation type: Operating tool
• Solid conductor: 0.5 … 2.5 mm² / 20 … 14 AWG
• Fine-stranded conductor: 0.5 … 2.5 mm² / 20 … 14 AWG
• Strip length: 5 … 7 mm / 0.2 … 0.28 inch
• Conductor connection direction to PCB: 0 °
• Pole No.: 3

Physical Data

• Pin spacing: 5/5.08 mm / 0.197/0.2 inch
• Width: 5 mm / 0.197 inch
• Height from the surface: 11 mm / 0.433 inch
• Depth: 9 mm / 0.354 inch

Pcb Contact

• PCB Contact: THT
• Solder pin arrangement: Over the entire terminal strip (in-line)
• Number of solder pins per potential: 1

Material Data

• Color: Gray
• Material group: I
• Insulation material: Polyamide (PA66)
• Flammability class per UL94: V0
• Clamping spring material: Chrome nickel spring steel (CrNi)
• Contact material: Electrolytic copper (ECu)
• Contact plating: Tin-plated
• Fire load: 0.000 MJ
• Weight: 2.898 g

Environmental Requirements

• Limit temperature range: -60 … +105 °C

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: IN
• GTIN: 4045454539788
• Customs tariff number Sales Organisation Germany: 85369010000
