804-104
Features
- PCB terminal strips with push-buttons and Push-in CAGE CLAMP® connection
- Push-in termination of solid and ferruled, fine-stranded conductors
- A large conductor entry accommodates conductors with a cross-section up to 12 AWG with an insulation diameter up to 4.2 mm
- Terminal strips with spacers to increase pin spacing
- Versions available with custom internal commoning (factory assembly), e.g., commoning ground conductor
Approvals
- UL International Germany GmbH, UL, E45171, UL 1977
- DEKRA Certification B.V., CCA, 71-110710, EN 60947-7-4
- UL International Germany GmbH, UL, E45172, UL 1059
- DEKRA Certification B.V., CCA, NTR NL 7781, EN 60947-7-4
- UL International Germany GmbH, ENEC 15, ENEC-00096, EN 60998
Specifications
Notes
- Variants:: Other pole numbers || Other colors || Mixed-color PCB connector strips || 10 mm pin spacing version with spacers || Direct marking || Versions for Ex i || Other versions (or variants) can be requested from WAGO Sales or configured at https://configurator.wago.com/
Ratings Per Iec/En
- Ratings per: IEC/EN 60664-1
- Nominal voltage (III/3): 250 V
- Rated surge voltage (III/3): 4 kV
- Rated voltage (III/2): 320 V
- Rated surge voltage (III/2): 4 kV
- Nominal voltage (II/2): 630 V
- Rated surge voltage (II/2): 4 kV
- Rated current: 24 A
- Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2
Ratings Per Ul
- Approvals per: UL 1059
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
Ratings Per Csa
- Approvals per: CSA
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
Connection 1
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Push-button
- Solid conductor: 0.25 … 2.5 mm² / 20 … 12 AWG
- Fine-stranded conductor: 0.25 … 2.5 mm² / 22 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 0.25 … 1.5 mm²
- Fine-stranded conductor; with uninsulated ferrule: 0.25 … 2.5 mm²
- Strip length: 10 … 11 mm / 0.39 … 0.43 inch
- Conductor connection direction to PCB: 0 °
- Pole No.: 4
Physical Data
- Pin spacing: 5 mm / 0.197 inch
- Width: 21.5 mm / 0.846 inch
- Height: 18.1 mm / 0.713 inch
- Height from the surface: 14.5 mm / 0.571 inch
- Depth: 15 mm / 0.591 inch
- Solder pin length: 3.6 mm
- Solder pin dimensions: 0.8 x 0.6 mm
- Drilled hole diameter with tolerance: 1.1 (+0.1) mm
Pcb Contact
- PCB Contact: THT
- Solder pin arrangement: Over the entire terminal strip (staggered)
- Number of solder pins per potential: 2
Material Data
- Color: Gray
- Material group: I
- Insulation material: Polyamide (PA66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (ECu)
- Contact plating: Tin-plated
- Fire load: 0.057 MJ
- Weight: 4.176 g
Environmental Requirements
- Limit temperature range: -60 … +105 °C
Commercial Data
- Packaging type: Box
- Country of origin Sales Organisation Germany: CH
- GTIN: 4044918515009
- Customs tariff number Sales Organisation Germany: 85369010000
