806-908

Specifications

Connection 1

• Pole No.: 8

Physical Data

• Pin spacing: 5 mm / 0.197 inch
• Width: 39.8 mm / 1.567 inch
• Height: 12 mm / 0.472 inch
• Depth: 2.7 mm / 0.106 inch
• Solder pin length: 3.4 mm
• Solder pin diameter: 1 mm
• Drilled hole diameter with tolerance: 1.3 (+0.05) mm

Mechanical Data

• Suitable: Pin spacing: 5 mm / 0.197 inch

Plug-In Connection

• Contact type (pluggable connector): Male connector/plug
• Connector (connection type): For PCB
• Mating direction to the PCB: 90 °

Pcb Contact

• PCB Contact: THT

Material Data

• Color: Black
• Fire load: 0.000 MJ
• Weight: 1.100 g

Commercial Data

• Packaging type: Box
• Country of origin Sales Organisation Germany: DE
• GTIN: 4044918368124
• Customs tariff number Sales Organisation Germany: 85369010000
